Product Description
JDA PL2000 mobile milling tshuab yog tsim los rau ntawm -site linear milling, nto milling, weld seam tshem tawm, tshav kub exchanger phua zawj, twj tso kua mis, thiab cov khoom siv mounting nto machining, thiab lwm yam. khw.
Nws lub caj npab milling yog ua los ntawm cov ntaub ntawv zoo tshaj plaws los txo tus kheej qhov hnyav kom ntau li ntau tau, thaum tuav lub zog txaus rau kev ua haujlwm hnyav milling. Lub feature txo qhov nyuaj ntawm hoisting, installation, thiab kev khiav hauj lwm ntau npaum li sai tau.
PL2000 mobile milling tshuab yog tsim los nrog milling stroke ntev 2000 hli (78.7 nti). Qhov luv luv lossis ntev milling stroke ntev kuj tuaj yeem lees txais raws li cov neeg siv khoom xav tau. Nws lub caj npab milling kuj tau sib xws nrog peb lub tshuab gantry milling. Nws ntau yam machining zog muaj xws li milling plat nto, flatness restoration, thiab keyway milling kev khiav hauj lwm.
Lub tshuab portable linear milling muaj rau lub ntsiab modular xws li milling caj npab, milling spindle taub hau, tsis siv neeg pub system, tsav lub cev muaj zog (hydraulic lossis servo), chav tsev fais fab, lub thawv hluav taws xob (servo tsav nkaus xwb), thiab mount puag. Cov neeg ua haujlwm ntawm qhov chaw muaj peev xwm ua tiav mount thiab pib ua haujlwm milling nyob rau hauv ib teev, raws li qhov nyuaj ntawm qhov chaw ua haujlwm thiab cov tshuab ua haujlwm.
Muaj plaub lub hauv paus muaj nyob rau hauv daim ntawv teev npe ntawm PL2000 mobile milling tshuab. Nyob rau ntawm qhov chaw machinists muaj peev xwm mount lub tshuab milling los ntawm bolts. Thiab lub hauv paus mount muaj ib theem adjustable muaj nuj nqi. Kev ua haujlwm ua kom cov kws ua haujlwm hauv chaw ua haujlwm kom ua tau zoo hloov kho qib lub tshuab tom qab nws tau nruab rau ntawm qhov chaw ua haujlwm- thooj.
Muaj ob txoj kev xaiv ntawm milling spindle taub hau: # 40 thiab # 50. #40 milling spindle taub hau tuaj yeem tuav lub ntsej muag siab tshaj plaws milling cutter 200 mm (7.8 nti) inch. Thiab # 50 milling spindle taub hau tuaj yeem tuav lub ntsej muag siab tshaj plaws milling cutter 250 mm (9.8 nti) inch.
FAQ
Q: Koj lub tshuab milling mobile puas tuaj yeem ua qhov milling?
A: Yog, peb lub tshuab milling tuaj yeem ua cov haujlwm milling nrog rau qhov kawg mills.
Q: Puas yog koj lub tshuab milling ntawm qhov chaw rau zeb tsis sib xws?
A: Yog, peb lub tshuab milling portable tuaj yeem siv los kho qhov tsis sib xws lossis puas.
Q: Koj puas muaj nyob rau hauv situ milling tshuab siv rau lub hauv paus phaj milling?
A: Yog, thov peb lub milling loj, ces peb tuaj yeem qhia koj tus qauv tsim nyog lossis kev cai ib qho.
Q: Lub teb milling tshuab puas ua tau precision milling?
A: Yog, peb lub tshuab milling portable tuaj yeem ua tiav qhov kev ua haujlwm siab.
Q: Puas yog koj lub tshuab milling portable rau milling structural steel nto?
A: Yog lawm, peb lub tshuab hluav taws xob portable steel milling feem ntau yog siv rau cov qauv hlau thiab cov khoom siv machining.
Q: Koj lub tshuab milling nyob qhov twg?
A: Tus nqi ntawm peb lub tshuab milling mobile feem ntau yuav yog USD 19, 002 - USD 130,002 nyob ntawm cov qauv thiab kev teeb tsa.
Q: Koj puas muaj cov cuab yeej siv tshuab siv rau flange nto milling?
A: Yog, peb muaj flange tig tshuab thiab flange milling tshuab raws li kev xaiv.
Q: Yuav ua li cas yog lub portable milling tshuab mounted?
A: Nws tuaj yeem txuas nrog bolts, sib nqus hauv paus, lossis customized clamps nyob ntawm qhov sib txawv ntawm cov khoom ua haujlwm.
Q: Koj puas tuaj yeem siv lub tshuab milling vertically?
A: Yog lawm, tag nrho peb cov tshuab milling tuaj yeem tsim thiab ua haujlwm milling vertically.
Q: Nws siv sijhawm ntev npaum li cas los teeb tsa lub tshuab milling onsite?
A: Cov txheej txheem kev teeb tsa ntawm lub tshuab milling feem ntau siv sijhawm 1 txog 2 teev nyob ntawm cov ntawv thov thiab qhov nyuaj.
Configure koj tus kheej portable milling tshuab hnub no!
